Vitrek V79 Ground Bond Tester, 1 to 30Arms, 50/60Hz

Product Highlights

• 4.3_ Color Touch Display – Easy To Use Intuitive User Interface
• 6 Functions Choose From – AC/DC Hipot, IR, Ground Bond, Continuity & Built-in Switching
• Made in the USA – Designed & Built in San Diego CA
• Compact, Lightweight, Rugged, Fan Free, Fast (100mS min test time) & Accurate
• 5KV AC/DC Hipot, 20mA max source current
• Ground Bond 1-30A RMS (42 A peak), 100µΩ Resolution
• 100 nano-Amp Leakage Current Resolution
• Low Cost of Ownership – 2 Year Calibration Interval
• USB 2.0, Serial/RS232, Digital I/O Interfaces are Standard
• Continuously Variable Insulation Resistance 20-5000V, 450GΩ Max
• Multi Mode IR with Steady/Rising Pass Mode
• Test Memory Stores up to 999 Steps and 60 Test Sequences
• Internal Self Test Fully Exercises Output and Verifies Current Accuracy
• Pre-Programmed Daily Verification Test With Optional PVD Test Load
• 150µS Safety Shutdown
• Ramped Discharge Capability
• Selectable ARC Detection 1-20mA
• Meets UL, CSA, IEC Safety Tester Requirements
• CE Safety Mark Certified to EN61010
• 2 Year Parts & Labor Warranty
