Rohde & Schwarz FSW13 for Rent, Signal and Spectrum Analyzer, 2 Hz - 13.6 GHz
Order #: FSW13-RENT3
Mfg #: FSW13
Request a Rental Quote
Have a Question? Speak to a Transcat Rental Expert: 800.264.4059
![Loading...](https://www.transcat.ca/static/version1724161005/frontend/Transcat/canada-en/en_US/images/loader-1.gif)
Product Highlights
The high performance Rohde & Schwarz (R&S) FSW13 Signal and Spectrum Analyzer is designed for convenience, accuracy and speed. Its unique touchscreen, straightforward, multiview result display, and optimized user guidance makes operation of the R&S FSW13 Analyzer efficient and convenient. With its unmatched phase noise, unparalleled dynamic range for spurious measurements, and high sensitivity even at low frequences, the R&S FSW13 guarantees high accuracy. Efficient measurement rates, rapid sweep times, quick switchover between instrument setups, makes operation fast and easy.
Features and Specifications of the Rohde & Schwarz FSW13 Signal and Spectrum Analyzer include:
Features of the R & S FSW13 Signal and Spectrum Analyzer:
- Excellent dynamic range for spurious measurements because of low DANL
- Harmonic measurements made easy and accurate due to integrated highpass filters:
- High sensitivity even at low frequencies
- Unparalleled dynamic range up to 1 GHz with separate receive path
- Up to 500 MHz analysis bandwidth
- High spurious-free dynamic range of > 100 dBc
- Large I/Q memory depth for seamless recording of long signal sequences
- Efficient operation with optimized user guidance
- MultiView: multiple results available at a glance
- Ideal for measuring oscillators for radar and communications applications as well as for analyzing radar systems:
- Fast identifcation and analysis of spurious emissions
- Measuring pulse parameters at the touch of a key
- Detection of widespread frequency-hopping signals
- Analyzing short pulse rise and fall times
- Identifying interaction between signals
- Multistandard radio analyzer (MSRA)
- Multistandard realtime analyzer (MSRT)
- High measurement rates and fast sweep times with sweep rates of up to 1000 sweeps/s
- Fast switchover between instrument setups
- Efficient measurement functions speed up operation
- Integrated support of R&SNRP-Zxx power sensors
Specifications of the Rohde & Schwarz FSW13 Signal and Spectrum Analyzer:
- Frequency:
- Frequency range: 2 Hz to 13.6 GHz
- Aging of frequency reference: 1 x 10-7/year
- With R&SFSW-B4: 3 x 10-8/year
- Bandwidths:
- Resolution bandwidths:
- Standard filter: 1 Hz to 10 MHz
- With R&SFSW-B8: 80 MHz
- RRC filter:
- NADC: 18 kHz
- TETRA: 24.3 kHz
- 3GPP: 3.84 MHz
- Channel filter: 100 Hz to 5 MHz
- Video filter: 1 Hz to 10 MHz
- I/Q Demodulation bandwidth: 10 MHz
- With R&SFSW-B28: 28 MHz
- With R&SFSW-B40: 40 MHz
- With R&SFSW-B80: 80 MHz
- With R&SFSW-B160: 160 MHz
- With R&SFSW-B320: 320 MHz
- With R&SFSW-B500: 500 MHz
- Displayed average noise level (DANL):
- 2 GHz: -156 dBm (1 Hz) typical
- With R&SFSW-B13: -159 dBm (1 Hz) typical
- 8 GHz: -156 dBm (1 Hz) typical
- 20 GHz: -150 dBm (1 Hz) typical
- DANL with preamplifier (with R&SFSW-B24):
- 8 GHz -169 dBm (1 Hz) typical
- 20 GHz -166 dBm (1 Hz) typical
- DANL with noise cancellation, preamplifier off, 2 GHz: -169 dBm (1 Hz) typical
- Intermodulation:
- Third-order intercept (TOI):
- f < 1 GHz: +30 dBm (typical)
- f < 3 GHz: +25 dBm (typical)
- 8 GHz to 26 GHz: +17 dBm (typical)
- 13.6 GHz to 40 GHz: +15 dBm (typical)
- WCDMA ACLR dynamic range:
- With noise cancellation: 88 dB
- Phase noise:
- 10 kHz offset from carrier:
- 500 MHz carrier: -140 dBc (1 Hz) typical
- 1 GHz carrier: -137 dBc (1 Hz) typical
- 10 GHz carrier: -128 dBc (1 Hz) typical
- Total measurement uncertainty: 8 GHz < .04 dB
-
