Amplifier Research 40S6G18B for Rent, Microwave Amplifier, 6 - 18 GHz, 40W
Microwave Amplifier, 6 - 18 GHz, 40W
Order #: 40S6G18B-RENT3
Mfg #: 40S6G18B
Call for price
Call for price
Amplifier Research 40S6G18B for Rent, Microwave Amplifier, 6 - 18 GHz, 40W
Microwave Amplifier, 6 - 18 GHz, 40W
Order #: 40S6G18B-RENT3
Mfg #: 40S6G18B
Call for price
Request a Rental Quote
Have a Question? Speak to a Transcat Rental Expert: 800.264.4059
Call for price
Product Highlights
The Amplifier Research 40S6G18B is a portable, self-contained, air-cooled, broadband, solid-state amplifier designed for applications that require instantaneous bandwidth, high gain and linearity.
Features and Specifications of the Amplifier Research 40S6G18B40S6G18B Amplifier include:
- Features:
- Provides a minimum of 40 watts of RF power instantaneously from 6 to 18 GHz when used with a sweep generator
- Digital Control Panel (DCP):
- Provides both local and remote control of the amplifier
- Uses a graphic Liquid Crystal Display:
- Provides gain settings
- Provides reports of internal amplifier status
- Uses menu assigned softkeys
- Uses a single rotary knob
- Uses a dedicated on/off switch
- Offers extensive control and status reporting capability
- Special features:
- Gain control
- Input overdrive protection
- All control functions and status indications are available remotely in GPIB/IEEE-488 format, RS-232 hardwire and fiber optic, USB, and Ethernet
- Bus interface connection back panel
- Keylock on front panel assures positive control of local or remote operation
- Low spurious signals, linearity, and load tolerance make it ideal for these various uses:
- RF susceptibility testing
- Antenna/component testing
- Communication technology testing
- As a test instrument covering multiple frequency bands
- Suitable for communication technologies including CDMA, W-CDMA, TDMA, GSM, UWB, WiMAX etc.
- Specifications:
- Rated power output: 40 watts minimum
- Power output @ 3dB compression:
- Nominal: 46 watts
- Minimum: 35 watts
- Power output @ 1dB compression:
- Nominal: 30 watts
- Minimum: 22 watts
- Flatness:
- typical: +/-2.0 dB
- maximum: +/-3.0 dB
- Frequency response: 6 - 18 GHz instantaneously
- Input for rated output: 1.0 milliwatt maximum, 0 dBm
- Gain (at maximum setting): 46 dB minimum
- Gain adjustment (continuous range): 10 dB minimum
- Input impedance: 50 ohms, VSWR 2.5:1 maximum
- Output impedance: 50 ohms, nominal
- Mismatch tolerance:
- 100% of rated power without foldback
- Will operate without damage or oscillation with any magnitude and phase of source and load impedance
- Modulation capability: Will faithfully reproduce AM, FM, or pulse modulation appearing on the input signal
- Harmonic distortion: Minus 20 dBc maximum at 40 watts
- Third order intercept point: 52 dBm typical
- Primary power (selected automatically):
- 90-132, 180-264VAC
- 50/60 Hz, single phase
- Connectors:
- RF input: Precision N female, rear
- RF output: Precision N female, rear
- Remote interfaces:
- IEEE-488: 24 pin female
- RS-232: 9 pin Subminiature D (female)
- RS-232 (fiber-optic): Type ST
- USB 2.0: Type B
- Ethernet: RJ-45
- Safety interlock: 15 pin Subminiature D
- Cooling: Forced air (self contained fans)
