Atlas Copco RTX-30 for Rent, Low Profile Hydraulic Torque Wrench Powerhead, 4770-31800 ft/lbs
Low Profile Hydr. Torq. Wrench Powerhead, 4770-31800 ft/lbs
Order #: RTX-30-RENT2
Mfg #: RTX-30-RENT2
Call for price
Call for price
Atlas Copco RTX-30 for Rent, Low Profile Hydraulic Torque Wrench Powerhead, 4770-31800 ft/lbs
Low Profile Hydr. Torq. Wrench Powerhead, 4770-31800 ft/lbs
Order #: RTX-30-RENT2
Mfg #: RTX-30-RENT2
Call for price
Call for price
Product Highlights
The RTX direct-fit, low profile wrenches are perfect for low-clearance application that require high-torque. RTX combine high power-to-weight ratio, durability and hands-free operation. Can be used with the standard setup, but can also be customized with hydraulic torque wrench accessories. Use of Aircraft quality aluminum alloy provides great strength capabilities, while keeping the weight to a minimum.
Noise & vibrations | |
---|---|
Sound uncertainty | 3 dB(A) |
Sound standard | ISO15744 |
Torque | |
Torque range min | 6466 Nm |
Torque range max | 43108 Nm |
Air information | |
Power supply hydraulic pressure range max | 690 bar |
Power supply hydraulic pressure range min | 104 bar |
Sound pressure | <70 dB(A) |
General | |
UK Regulations | S.I. 2008/1597 |
UK Standard | EMC Directive 2004/108/EC||EN 50581||EN 60204-1||EN 61000-6-2||EN 61000-6-4||EN 809||EN ISO 12100||EN ISO 4413||RoHS Directive 2011/65/EU |
Certifications, standards & directives | |
EU Directives | 2006/42/EC (MD) |
EU Standard | EMC Directive 2004/108/EC||EN 50581||EN 60204-1||EN 61000-6-2||EN 61000-6-4||EN 809||EN ISO 12100||EN ISO 4413||RoHS Directive 2011/65/EU |
ATEX | No |
Dimension & weight | |
L | 457 mm |
NS max | 155 mm |
NS min | 90 mm |
R | 25.4 mm |
Ratched link hex size max | 165 mm |
Ratched link hex size min | 90 mm |
W1 | 83 mm |
W2 | 132 mm |
Weight | 35.5 kg |
