Ralston Instruments XTHP-1MSA

Product Highlights

Ralston Instruments 10,000 psi Hydraulic hand pump is an excellent way to generate high pressure for use in calibration and testing. The pump comes with a hose and process connection, bottle and optional pressure gauge or FieldLab for a complete calibration kit.

• Easily pump to 10,000 psi without without having to lock a stroke limiting knob
• Stainless steel for all wetted parts makes pressure very stable, especially at high pressure
• Priming module allows the user to quickly fill a hose or device under test before pumping with handle
• Includes Quick-test XT 10,000 psi adapters and hoses for hand tight connections in the field
• Lightweight 3 lb/1.4 kg and compact so easy to hold and pump with one hand
• Well balanced because pressurized section is below the reservoir
• Compatible with water, ethylene glycol, antifreeze, windshield wiper fluid, hydraulic oil, mineral oil and alcohol
• Unique reservoir material is highly resistant to shock, extreme temperature and chemical exposure
• Bleed/Vent valve has metal to metal seat for excellent sealing at any pressure
• Made in the USA

Each Unit Includes

• XTHP Hydraulic hand pump
• 3 ft Quick-test test hose
• 1/4" Male NPT process adapter
• Bottle
