NOSHOK 612

Level Transmitter, 100" H2O .25%A, 4-20mA, 50' Cable

Order #: 612-100INH2O-1-1-N-50

Mfg #: 612-100INH2O-1-1-N-50

$1,830.62

Availability: Ships in 3-4 weeks

Add Calibration

Qty

Output signal : 4 to 20 mA - 3 wire, 0 to 5 Vdc - 3 wire, 0 to 10 Vdc - 3 wire, 0 to 10 Vdc - 3 wire, 0.5 - 2.5 Vdc - 3 wire
Proof Pressure : 2 times Full Scale
Burst Pressure : 4 times Full Scale
Accuracy : ± 0.25% Full Scale
Repeatability : ± 0.05% Full Scale
Hysteresis : ± 0.1% Full Scale
Stability : ± 0.2% Full Scale for 1 year, non accumulating
Temperature Ranges : Compensated : 32 °F to 175 °F (0 °C to 80°C), Zero Effect - ± 0.011 % /°F within compensated range, Span Effect - ± 0.011 % /°F within compensated range, Storage : - 76 °F to 221 °F (-60 °C to 105 °C), Media : - 22 °F to 212 °F (-30 °C to 100°C), Ambient : - 22 ° to 212°F (-30 °C to 100 °C)
Response Time : 1ms
Pressure cycle limit : 150 Hz
Environmental protection : NEMA 6P, IP68
Electromagnetic Rating : CE compliant to EMC norm EN61326: 1997/A1: 1998 RFI, EMI and ESD protection
Shock : Less than ± 0.05 % Full Scale effect for 100 g's at 20ms on any axis
Vibration : Less then ± 0.01 % Full Scale effect for 15 g's at 0 to 2000 Hz on any axis
Weight : 7 oz
