Additel 992 Handheld Pneumatic Pressure Pump, 700 psi

Product Highlights

The ADT992 Handheld Pneumatic Pressure Pumps offer a pressure range from 95% vacuum to 700 psi (50 bar), making them highly versatile for a wide range of applications. The ADT992 has a maximum pressure of 700 psi, while the ADT993 extends up to 1,000 psi. Designed for ease of use, the dual stage pre-pressure piston provides a broad pressure range and energy-efficient performance. The pump quickly stabilizes pressure with its lever-type pressurization system, and the fine adjustment screw ensures precise pressure settings. Its longitudinal layout enhances control during operation, and four different operating positions allow users to adapt to various work requirements, making it an ideal, modern replacement for traditional handheld pressure pumps.

• Pressure Range: Up to 700 psi (50 bar)
• Dual Stage Piston: Higher pressure with less effort
• Multi-position versatility for on-site use
• Lever Pressurization: Efficient and quick stabilization
• Portable: Weighs 3.5 lb (1.6 kg)
• Low Maintenance

• Media: Air
• Generated Pressure Range:
  • ADT992: 95% vacuum to 700 psi (50 bar)
  • ADT993: 95% vacuum to 1,000 psi (70 bar)
• Adjustment Resolution: 10 Pa (0.1 mbar)
• Minimum Pre-pressure: 600 psi (40 bar)
• Boost Pressure of Lever Stroke: +30 psi (2 bar) / stroke
• Maximum Load Volume: 35 ml
• Maximum Volume of Fine Adjustment: 7.2 ml
• Port Filters:
  • Standard Port: 150µm quick removal filter
  • Pump Air Intake Port: 100µm quick removal filter
  • Pressure Outlet: 150µm quick release filter
• Material:
  • Ram/Adapters: SS (Stainless Steel)
  • Body: SS (Stainless Steel), Aluminum
  • Seals: Buna-N, PTFE, Copper Alloy
• Dimensions:
  • Height: 4.8" (122mm)
  • Base: 12.6" (320mm) x 4.3" (110mm)
• Warranty: 1 year

Each Unit Includes

• O-ring: 20 pcs
• Flexible hose (Maximum pressure:630 bar)
• ADT100-X-FNG (one female quick connector for DUT)
• (X - designated by base model ordered)
• Carrying case (992/993-X-SETmodels only)
