Enerpac RC-50 Gen.Purpose Hydraulic Cylinder, 4.9 Ton Capacity, .63" Stroke
Gen.Purpose Hydraulic Cylinder 4.9 Ton Capacity,.63" Stroke
Order #: RC50
Mfg #: 300549
$686.00
Enerpac RC-50 Gen.Purpose Hydraulic Cylinder, 4.9 Ton Capacity, .63" Stroke
Gen.Purpose Hydraulic Cylinder 4.9 Ton Capacity,.63" Stroke
Order #: RC50
Mfg #: 300549
Product Highlights
- Unique GR2 Bearing Design, reduces wear, extending life
- Base mounting holes enable easy fixturing
- Designed for use in all positions
- High strength alloy steel for durability
- Redesigned cylinder thread protector for ease of use
- Heavy-duty, pretensioned spring improves retraction speed
- Baked enamel finish for increased corrosion resistance
- CR-400 coupler and dust cap included on all models
- Plunger wiper reduces contamination, extending
Cylinder capacity | 5 tons (4.9 maximum) |
Stroke length | 0.63 inches |
Effective area | 0.99 square inches |
Oil capacity | 0.62 cubic inches |
Cylinder bore diameter | 1.13 inches |
Collapsed height | 1.63 inches |
Extended height | 2.25 inches |
Outside diameter | 2.31 inches |
Weight | 2.2 lb. |
