Fluke 719PRO-300G Electric Pressure Calibrator, 300PSIG
Electric Pressure Calibrator, 300PSIG
Order #: 719PRO 300G
Mfg #: 4353234
$6,918.31
Fluke 719PRO-300G Electric Pressure Calibrator, 300PSIG
Electric Pressure Calibrator, 300PSIG
Order #: 719PRO 300G
Mfg #: 4353234
$6,918.31
The 719Pro includes a full functioning loop calibrator that sources, simulates and measures mA signals and more making it the ideal test tool for calibrating high accuracy transmitters, pressure switches and pressure gauges.
Get the ultimate in measurement flexibility with the large backlit screen, which displays three parameters at once:
• Pressure measurement from internal or external sensor
• Sourced/simulated or measured mA values
• Temperature measured by optional RTD probe
Availability:
In stock
Product Highlights
- Unique integrated electric pump for one handed pressure calibration
- Test pressure switches easily with easy-to-use switch test function
- Precision pressure adjust vernier for easy and accurate pressure calibration
- Ideal accuracy and performance (0.025 %) for reference class transmitter calibration
- 30 PSI, 150 PSI and the new 300 PSI pressure ranges
- Programmable pressure calibrator pump limit:
- - eliminates over-pressurization
- - allows the user to program target pressures for pumping
- Extended pressure measurement range with any of 29 700Pxx Pressure Modules
- Pump cleanout ports reduce pump failures from moisture and fluid damage
- Fluid trap included with the unit to mitigate chance of fluid damage in at-risk applications
- Precision temperature measurement with optional RTD probe
Each Unit Includes
- Protective Yellow Holster
- Instructions Sheet (15 languages)
- Test Leads and Alligator Clip
- 8 standard alkaline AA batteries
- Hose Kit
- NIST - Traceable calibration report and data
Webinars
-
Transcat 5353C-GCalibration Labels-Green, Self-Laminating, 1 3/4x5/8"Order #: 5353C-G
Mfg #: CUSTOM QCC306-GR (QZ0530GR)
Availability:In stockSpecial Price $32.11 Regular Price $33.81 -
Fluke 750P Series Pressure ModulesConfigure your Fluke 750 Series Pressure Module today!
Order #: 750P
Mfg #: 750P
Availability:In stock$2,296.75 -
Fluke 700PTP-1 Pneumatic Test Pump, -13 to 600PSIPneumatic Test Pump, -13 to 600PSI
Order #: 700PTP-1
Mfg #: 2811774
Availability:In stock$1,440.23 -
Fluke 700PTPK2 Premium Pneumatic Test Pump KitPremium Pneumatic Test Pump Kit
Order #: 700PTPK2
Mfg #: 4623306
Availability:In stock$2,392.23 -
Fluke 720RTD RTD Probe for 721 & 719PRO Pressure CalibratorsRTD Probe for 721 & 719PRO
Order #: 720RTD
Mfg #: 4366669
Availability: Ships in 3-4 weeksSpecial Price $480.86 Regular Price $579.35 -
Fluke 720URTDA Universal RTD adapter for 721 and 719Pro Pressure CalibratorsUniversal RTD adapter for 721 and 719Pro
Order #: 720URTDA
Mfg #: 4382695
Availability: Ships in 3-4 weeksSpecial Price $375.88 Regular Price $452.87 -
Fluke TLK-220 US SureGrip Accessory Set with Meter Carrying CaseUS SureGrip Accessory Set w/Meter Carrying Case
Order #: TLK-220
Mfg #: 2097010
Availability:In stockSpecial Price $247.19 Regular Price $297.83 -
Fluke 700TTH5K Premium Pressure Transmitter Test Hose KitPremium Pressure Transmitter Test Hose Kit
Order #: 700TTH5K
Mfg #: 4623323
Availability:In stockSpecial Price $838.69 Regular Price $1,010.47
| Specifications | ||||
| Pressure Measurement | ||||
| Range | -12 to 300 PSI / -0.8 to 20 bar | |||
| Resolution | 0.01 PSI, 0.001 bar | |||
| Accuracy (1 year) | ± 0.025 % of full scale, 6 months ± 0.035 % of full scale, 1 year Dry Air and non-corrosive gas only |
|||
| Temperature effect (all ranges) | Add ± 0.002 % F.S./°C for temps outside of 15 °C to 35 °C No effect on accuracy on all functions from 15 °C to 35 °C |
|||
| Function | Range | Resolution | Accuracy (1 year) | Comment |
| mA dc (simulation and measurement) | 0-24 mA dc | 0.001 mA | ± 0.015 % of reading ± 2 counts | 1000 ohm maximum load in mA source, 26 V dc maximum voltage in mA simulate |
| Volts dc (measurement only) | 30 V dc | 0.001 V | ± 0.015 % of reading ± 2 counts | No AC voltage measurement, do not exceed 30 V dc |
| Temperature (measurement only, Pt100 RTD) | -50 to 150 °C (-50 °F to 302 °F) | 0.01 °C 0.01 °F | Temperature ± 0.1 °C (0.2 °F) | ± 0.25 °C (± 0.45 °F) combined uncertainty when using 720 RTD probe (optional accessory) |
| Loop power supply | 24 V dc | N/A | 24 mA at 24 V | |
| Temperature effect (all functions) | Add ± 0.002 % F.S./°C for temps outside of 15 °C to 35 °C | No effect on accuracy on all functions from 15 °C to 35 °C | ||
| Environmental | ||||
| Operating temperature | -10 °C to +50 °C | |||
| Storage temperature (with batteries) | Per battery manufacturer's specification within storage specification below | |||
| Storage temperature (without batteries) | -20 °C to +60 °C | |||
| Power Requirements | ||||
| Battery | Eight (8) standard Alkaline AA batteries | |||
| Battery life | 300 pump cycles to 150 PSI minimum; 1000 pump cycles to 30 PSI; 100 pump cycles to 300 PSI minimum | |||
| Physical | ||||
| Dimensions (HxWxD) | 24.13 cm x 11.18 cm x 7 cm (9.5 in x 4.4 in x 2.8 in) | |||
| Weight | With holster 1.2 kg (2.5 lb) | |||
| Connections | ||||
| Pressure | 1/8 inch female NPT | |||
| Electrical | Standard banana jacks | |||
| RTD | 4 pin miniature circular | |||
| External module | 6 pin miniature circular | |||
| Engineering Units (Configurable) | ||||
| psi, bar, mbar, kPa, kgcm2, cmH2O@4 °C, cmH2O@20 °C, mH2O@4 °C, mH2O@20 °C, inH2O@4 °C, inH2O@20 °C, inH2O@60 °F, mmHg@0 °C, inHg@0 °C, ftH2O@4 °C, ftH2O@20 °C, ftH2O@60 °F | ||||
