MadgeTech VOLT101A-15V
Order #: VOLT101A-15V
Mfg #: 901840-00
Product Highlights
Low Level, -1 V to 16 V, DC Voltage Recorder
The Volt101A is a compact, low-level DC voltage data logger. Includes standard calibration certificate.
- Compact Size
- 10-Year Battery Life
- 3 Measurement Ranges
The Volt101A is a compact, low-level DC voltage data logger. This device is available in four ranges: 2.5VDC, 15VDC, 30VDC and ±160mVDC.
With a user-programmable reading rate of up to 4 Hz, 10-year battery life and the ability to store up to 2,095,104 readings, the Volt101A is ideal for long-term studies. Connect negative and positive wire leads directly to the terminal block on the Volt101A to monitor and measure voltage levels. The terminal block easily disconnects to retrieve the logger for data download without disrupting wiring connectivity.
The Volt101A is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.
Memory | 2,095,104 readings |
Reading Rate | 4 readings every second up to 1 reading every 24 hours |
Baud Rate | 115,200 |
LED Indicators | Red & Green |
Battery Life | 10 years typical at a 15 minute reading rate |
Material | Polycarbonate |
Dimensions | 1.4 in x 2.1 in x 0.6 in (35 mm x 54 mm x 15 mm) |
Operating Environment | -40 °C to +80 °C (-40 °F to +176 °F), 0 %RH to 95 %RH non-condensing |
Required Interface Package | IFC200 |
Approvals | CE |
Voltage Range | ±160 mVDC, 0 to 2.5 VDC, 0 to 15 VDC, 0 to 30 VDC |
Voltage Resolution | ±160 mVDC: 5 ?V, 0 to 2.5 VDC: 0.1 mVDC, 0 to 15 VDC: 0.5 mVDC, 0 to 30 VDC: 1.0 mVDC |
Voltage Calibrated Accuracy | ±160 mVDC: ±0.01 %FSR @ 25 °C (77 °F), 0 to 2.5 VDC: ±0.05 %FSR @ 25 °C (77 °F), 0 to 15 VDC: ±0.05 %FSR @ 25 °C (77 °F), 0 to 30 VDC: ±0.05 %FSR @ 25 °C (77 °F) |
