Keysight 8481D Power Sensor, 10MHz to 18GHz, -70 to -20dBm

Product Highlights

The 8481D diode sensor operates with the EPM series, EPM-P series, 70100A, E1416A and the discontinued 43X power meters, from -70 to -20 dBm.

• Excellent SWR for reducing mismatch uncertainty
• Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
• Compatible with EPM (N1913A/ 14A, E4418B/ 19B), EPM-P (E4416A/ 17A) and P-series (N1911A/ 12A) power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
• Accurate average power measurements over -70 to -20 dBm
• Frequency range 10 MHz to 18 GHz
• Diode power sensing element

The Keysight 11708A 30 dB attenuator is supplied with 8480 series power sensors with the “D” suffix, for calibration with the power meter 0 dBm, 50 MHz reference.
