Druck DPI620G Genii Advanced Multifunction Calibrator with HART, Profibus

Product Highlights

• With HART and Profibus

DPI 620 Genii Advanced Modular Calibrator and HART/Foundation Fieldbus Communicator. This ultra-compact electrical, frequency and temperature calibrator with full HART communicator and optional Foundation Fieldbus communicator provides simultaneous measurement and source capabilities for the setup, testing and calibration of most types of process instruments including transmitters, transducers, gauges/indicators, switches, proximity detectors, counters, RTDs, thermocouples and valve positioners.

Features

• Multi-function capabilities: electrical, frequency, temperature and pressure
• Optional HART and Foundation Fieldbus Communicators
• ATEX and IECEx approved for hazardous area use
• Modular re-rangeable and expandable concept
• Individual components can be used as stand-alone instruments
• Allows significant inventory reductions
• Simplifies training and improves operator safety
• Reduces cost of ownership
• High resolution touch display and UI (user interface) supporting gestures and swipes for a flatter menu structure and greater ease of use
• HART and Foundation Fieldbus digital communication with complete device description libraries, internal modems and free of charge upgrades
• ATEX and IECEx approved system for use in zone 1 and 2 classified hazardous areas
• UI DASHBOARD to quickly launch applications such as CALIBRATOR, HART and Foundation Fieldbus
• TASK menu allows single touch configuration for common devices such as pressure and temperature transmitters, transducers, switches, and valve positioners. Most used and user configured tasks can be added to FAVOURITES.
• All first generation DPI620 and the new Genii system components are fully interchangeable e.g. pressure stations, pressure modules and all accessories

Dashboard applications: Calibrator

• One touch selection of common tasks, e.g. P to I for a pressure transmitter
• Highest accuracy for measuring, sourcing and simulating electrical, frequency, temperature and pressure
• Simulate device inputs and measure outputs simultaneously
• Calculates errors between inputs/outputs
• Pressure system generates 100 bar/1,500 psi pneumatic and 1,000 bar/15,000 psi hydraulic pressures.
• Interchangeable pressure modules from 25 mbar/10 inH2O to 1,000 bar/15,000 psi

Documenting

• Data log up to six channels simultaneously
• Automate calibration procedures and Document As Found and As Left results
• Store a complete plant database of procedures and results
• View standard office documents, including images, text files, spreadsheets and presentations
• Compatible with calibration management software

HART Communicator

• Measure and source analogue variables without secondary calibration equipment
• No power during shutdown? Genii provides loop power 24 V or 28 V (Genii-IS series 15V)
• Need a 250 ohm resistor? Just select from the menu
• It's easy to upgrade Genii with free of charge software and latest DD library
• View, change, clone and store device configurations
• Work off -line to create and change configurations
• Transfer device configurations to your PC

Foundation Fieldbus communicator - optional

• Fully featured fieldbus communicator for device configuration and calibration
• Complete device description library
• It's easy to upgrade Genii with free of charge software and latest DD library

The Druck DPI 620 Genii Series - Advanced Modular Calibrator and HART/Fieldbus Communicator comprises four system components to provide the multi-functionality to perform duties formerly requiring a wide range of different instruments. These system components are:

• DPI620G - Multi-function calibrator, HART/Fieldbus Communicator
• DPI620G-IS - Intrinsically Safe Multi-function calibrator, HART/Fieldbus Communicator

Note: All previous generation DPI 620 series and the new DPI 620 Genii series products (including accessories) are compatible with each other.
