Siglent SSG3021X
RF Signal Generator 2.1 GHz; -110 dBm; 5" touch-screen
Order #: SSG3021X
Mfg #: SSG3021X
$3,703.00
Product Highlights
- Frequency up to 2.1 GHz/3.2 GHz
- 0.01 Hz frequency setting resolution
- Level output from -110 dBm to +13 dBm
- Maximum level up to +20 dBm (typ.)
- Phase Noise : -110 dBc/ Hz @ 1 GHz , 20 kHz offset (typ.)
- Level accuracy ≥0.7 dB (typ.)
- Provides AM, FM, &PM analog modulation with internal, external or Int+Ext source
- Pulse modulation, on/off ratio ≥70 dBc
- Pulse train Generator (option)
- External IQ modulation with SDG6000X as the baseband IQ signal
- USB-power meter measurement kit
- 5 inch TFT capacitive touch screen, Mouse and keyboard supported
- Web Browser Remote Control on PC and mobile Terminals
- Standard interface include USB Host, USB Device (USB TMC), LAN (VXI-11, Socket, Telnet). Optional interface: GPIB
Each Unit Includes
- quick start, an USB cable, calibration certificate, power cord
