Rice Lake Weighing Systems RL20001-T10-3K

Alloy Steel,S-Beam Load Cell 20ft.3mV/350V

Order #: 21409

Mfg #: 21409

Questions about availability or need help? Contact Us:

Special Price $460.92 Regular Price $501.00

Qty

Rice Lake Weighing Systems RL20001-T10-3K

Alloy Steel,S-Beam Load Cell 20ft.3mV/350V

Order #: 21409

Mfg #: 21409

Special Price $460.92 Regular Price $501.00

Availability: Ships in 3-4 weeks

Load Cell,SBM RL20001-T10 -3K 3000lb 20ft 3mv/v 350 Ohm NTEP III 5S/IIIL 10S FM WW IP67
Full Scale Output: 3.0 mV/V
Output Resistance: 350 (± 3) ohms
Input Resistance: 385 (± 5) ohms
Material/Finish: High-alloy steel, nickel plated
Temperature: Compensated range 14° F to 104° F/-10° C to 40° C Operating range -40° F to 150° F/-40° C to 65° C
Seal Type: Environmentally sealed, IP67
Safe Overload: 150% full scale
Rated Excitation: 5-10 V AC/DC (15 V maximum)
Nonlinearity: 0.03% full scale
Hysteresis: 0.02% Full scale
Insulation Resistance: 5,000 megohms
Cable Length: 20 ft (6.1 m)
Cable Diameter: 200 polyurethane jacket
Cable Color Code: Red......................+ Excitation Black.......................– Excitation Green .........................+ Signal White ......................– Signal
Warranty: Two-year limited warranty
Approvals: FM Approved NTEP CE
