Keysight / Agilent E8364C for Rent, Network Analyzer, 10MHz to 50GHz

Product Highlights

Agilent E8364C Network Analyzer is part of Agilent PNA series of network analyzer (Performance Network Analyzers) and feature the highest levels of accuracy for your critical needs. The Agilent E8364C has a wide frequency range of 10 MHz to 50 GHz and has 2-Ports and 4 Receivers. An integrated S-parameter test set with four receivers allows true TRL calibration. TRM/LRM calibration, on-wafer, in-fixture, waveguide and antenna measurements are all part of this Network Analyzers capabilities. A large 8.4 LCD front panel display with touch screen (1024x768 resolution) is integrated into the instrument. Enhanced Windows graphical user interface. Hard keys and soft keys for simple operation without a mouse are featured. And an optional configurable test set is available with option 14.

Features and specifications of the Agilent E8364C Network Analyzer include:

• < 26 usec/point measurement speed
• Measurement channels: 32 independent measurement channels
• Measured number of points per sweep: User definable from 2 to 20,001
• System Dynamic range up to 50 GHz: 104 dB standard at 10 Hz IF bandwidth
• Amplifier gain compression, harmonic, IMD, and pulsed-RF
• Mixer conversion loss, return loss, isolation, and absolute group delay
• Trace noise: < 0.006 dB rms at 1 kHz IF bandwidth standard and with option 14
• Nominal power: -12 dBm standard, -17 dBm with options 14 and UNL
• Frequency resolution: 1 Hz
• Phase noise: -50 dBc at 1 kHz offset nominal
• Test port noise floor: < -114 dBm 10 Hz IF bandwidth standard
• IF bandwidth range: 1 Hz to 40 kHz, nominal
• RF connectors 2.4mm male (50ohm)
• VGA video output-15-pin mini D-Sub
• Interfaces:
  • GPIB-Two ports: dedicated controller and dedicated talker/listener
  • USB-1 port on front panel and 4 ports on rear panel
  • LAN-10/100 BaseT Ethernet; 8-pin configuration auto selects
