Keysight DP0033A Probe, differential, 200 MHz, 3000 V

Product Highlights

Keysight Technologies' DP003xA Series of high-voltage, differential active probes provide superior general-purpose differential signal measurements required for high-speed power measurements such as measuring characteristics of switching power devices, DC-DC converters or class D amplifiers, automotive bus measurements, and high-speed digital system designs. As designs become more complex and the need for floating measurements grows, these differential probes enable floating measurements between any two points on a board and can also function as single-ended probes with one terminal connected to ground. The DP003xA Series differential active probes are available in bandwidth models ranging from 25 MHz to 200 MHz with a wide input dynamic range of up to +/- 7000 V.

The DP003xA series probes are equipped with either Keysight Technologies' AutoProbe1 interface or a standard BNC interface. Probe models DP0031A/32A/33A/34A are designed with Keysight's AutoProbe1 interface, which provides power, offset calibration, and auto-configuration including attenuation settings without having to remove the probe from the scope or DUT.

The DP003xA series of probes are compatible with most of Keysight's InfiniiVision and Infiniium oscilloscopes that provide 1-MOhm input terminations with the AutoProbe1 interface.

• Bandwidth: 200 MHz
• Attenuation (high/low): 1000/100:1
• Max differential measurement range (DC + AC peak): +/-3000 / +/-300V
• Oscilloscope interface: AutoProbe1
