Hioki 3490 Analog Megohmmeter, 3-Range, 250 to 1000V

Product Highlights

• 3-range testing voltage, Insulation meter
• Continuity check, 3? range via 200mA testing
• Luminous scale
• Check for live circuits
• Check for the battery status
• Testing voltage 250 V DC, 500 V DC, 1000 V DC
• Rated resistance 100 MΩ, 100 MΩ, 4000 MΩ
• Accuracy 1st effective measuring range ±5 % of indicated value 0.05 to 50 MΩ, ±5 % of indicated value 2 to 1000 MΩ
• Rated measurement current 1 mA
• Low resistance 3 Ω range, ±0.09 Ω accuracy, 200 mA DC measuring current, 4.1 to 6.9 V open-circuit voltage
• AC voltage range 0 to 600 V (50/60 Hz), ±5 % of maximum scale value accuracy,
• 100 kΩ or more input resistance
• Other functions Luminous scale, Battery status check, Live circuit check
• Power consumption AA alkaline (LR6) battery × 4, Continuous use: 20 hours (at 500 V range, no load)
• Dimensions, mass 159 mm (6.26 in)W × 177 mm (6.97 in)H × 53 mm (2.09 in)D, 610 g (21.5 oz), (including battery, not including test lead)

Each Unit Includes

• Test lead
• Operation manual
• Shoulder strap
• AA alkaline battery (LR6)
