Overview |
|
Color Alarm (Isotherm) |
Above, Below, Interval, Condensation (moisture/humidity/dewpoint), Insulation |
Difference Temperature |
Yes |
Display |
4", 640 x 480 pixel touchscreen LCD with auto-rotation |
Display Technology |
IPS |
Housing material |
PCABS with TPE, magnesium |
Laser Alignment |
Position is automatically displayed on the infrared image |
Laser Pointer |
Class 2, 0.05–40 m (0.16–131 ft) ±1% of measured distance |
Packaging Size |
500 x 190 x 370 mm (19.7 x 7.5 x 14.6 in) |
Programmable Buttons |
2 |
Size (L x W x H) |
Lens horizontal: 140 x 201.3 x 167.3 mm (5.5 x 7.9 x 6.6 in) |
Time Lapse [Infrared] |
10 sec to 24 hrs |
Voice |
60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth |
Connections & Communications |
|
Audio |
Microphone and speaker for voice annotation of images |
METERLiNK |
Wireless connection (Bluetooth) to: FLIR meters with METERLiNK |
METERLiNK - Bluetooth |
Communication with headset and external sensors |
Remote Control |
Using USB cable or Wi-Fi |
Setup Commands |
Local adaptation of units, language, date, and time formats |
Storage Media |
Removable SD card |
USB |
USB Type-C: data transfer/video/power |
USB - Standard |
USB 2.0 High Speed |
Video Out |
DisplayPort over USB Type-C |
Environmental |
|
EMC |
ETSI EN 301 489-1 (radio), ETSI EN 301 489-17, EN 61000-6-2 (immunity), EN 61000-6-3 (emission), FCC 47 CFR Part 15 Class B (emission) |
Emissivity Correction |
Yes, variable from 0.01 to 1.0 or selected from materials list |
Humidity (Operating and Storage) |
IEC 60068-2-30/24 hours, 95% relative humidity, 25–40°C (77–104°F)/2 cycles |
Operating Temperature Range |
-15°C to 50°C (5°F to 122°F) |
Radio Spectrum |
ETSI EN 300 228, FCC Part 15.249, RSS-247 Issue 2 |
Safety |
EN/UL/CSA/PSE 60950-1 |
Shock & Vibration & Encapsulation |
25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6 / IP 54; EN/UL/CSA/PSE 60950-1 |
Storage Temperature Range |
-40°C to 70°C (-40°F to 158°F) |
Tripod Mounting |
UNC 1/4"-20 |
Imaging & Optical |
|
Aspect ratio |
4:3 |
Auto Rotation |
Yes |
Camera software update |
Using USB cable or SD card |
Color |
Black |
Color Depth |
24 |
Color Palettes |
Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC |
Detector Type and Pitch |
Uncooled microbolometer, 12 µm |
Digital Camera |
5 MP, with built-in LED photo/video lamp |
Digital Camera Focus |
Fixed |
Digital Camera FOV |
53° x 41° |
Digital Zoom |
1–8x continuous |
Field of View |
14° x 10° |
Field of view match |
Yes |
f-number |
1.5, 14° |
Focal Length |
29 mm (1.41 in) |
Focus |
Continuous with laser distance meter (LDM), one- shot LDM, one-shot contrast, manual |
Frame Rate [Full Window] |
30 Hz |
Gallery |
Yes |
Global Positioning System [GPS] |
Location data automatically added to every still image and first frame in video from built-in GPS |
Image Adjustment |
Automatic, automatic maximum, automatic minimum, manual |
Image Frequency |
30 Hz |
Image Sketch |
From touchscreen, on infrared image only |
Lens |
14° |
Lens Identification |
Automatic |
Minimum Focus Distance |
1.0 m (3.28 ft) |
Minimum Focus Distance with MSX |
1.0 m (3.28 ft) |
Non-Radiometric IR or Visual Video |
H.264 to memory card |
Non-radiometric IR video streaming |
H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi |
Picture-in-Picture |
Resizable and movable |
Radiometric IR video recording |
Real-time radiometric recording (.csq) |
Radiometric IR video streaming |
Over UVC |
Spatial resolution (IFOV) |
0. 4 mrad/pixel |
Spectral Range |
7.5 - 14 µm |
Thermal Sensitivity/NETD |
<50 mK @ 30°C (86°F) |
UltraMax |
Quadruples pixel count; activated in menu and processed in FLIR Tools |
Video Lamp |
Built-in LED light |
Viewfinder |
No |
Viewing Angle |
80° |
Visual Image |
Yes |
Visual Video Recording |
H.264 to memory card |
Visual Video Streaming |
Yes |
Measurement & Analysis |
|
Accuracy |
±2°C (±3.6°F) or ±2% of reading |
Area measurement information |
Yes |
Automatic hot & cold detection |
Automatic maximum/minimum markers within area |
Languages |
21 |
Laser Distance Meter |
Yes; dedicated button |
Measurement Corrections |
Yes |
Measurement Function Alarm |
Audible/visual alarms (above/below) on any selected measurement function |
Measurement Presets |
No measurements, center spot, hot spot, cold spot. User Preset 1, User Preset 2 |
Object Temperature Range |
-20°C to 120°C (-4°F to 248°F); 0°C to 650°C (32°F to 1202°F); 300°C to 1500°C (572°F to 2732°F) |
Reference Temperature |
Yes |
Spotmeter and Area |
3 ea. in live mode |
Meter Data |
|
Cover Glass Material |
Dragontrail® |
Other |
|
Touch Screen |
Optically bonded PCAP |
Physical |
|
Weight [battery included] |
1.4 kg (3.1 lb) |
Power |
|
Battery operating time |
Approx. 4 hours at 25°C (77°F) ambient temperature and typical use |
Battery size (L x W x H) |
59 x 66 x 94 mm (2.3 x 2.6 x 3.7 in) |
Battery Type |
Li-ion battery, charged in camera or on separate charger |
Battery voltage |
3.6 V |
Battery weight |
195 g (6.89 oz) |
Charging system |
In camera (AC adapter or 12 V from a vehicle) or two-bay charger |
Charging Temperature |
0°C to 45°C (32°F to 113°F) |
Charging Time (using two-bay charger) |
3.5 h to 90% capacity, on-screen indicator |
External Power Operation |
AC adapter 90–260 V AC (50/60 Hz) or 12 V from a vehicle (cable with standard plug, optional) |
Power Management |
Automatic shut-down and sleep mode |
Shipping Information |
|
Packaging |
Infrared camera with lens, 2 batteries, battery charger, hard transport case, lanyards, front lens cap, power supplies, printed documentation, SD card (8 GB), cables (USB 2.0 A to USB Type-C, USB Type-C to HDMI, USB Type-C to USB Type-C) |
Storage Media |
|
Image File Format |
Standard JPEG with measurement data included |
Thermal Imaging |
|
Detector Resolution |
640 x 480 |
