Enerpac RWH121 Holl-O-Cylinder, 1"Stroke
Holl-O-Cylinder,1"Stroke
Order #: RWH-121
Mfg #: RWH121
$1,397.20
Enerpac RWH121 Holl-O-Cylinder, 1"Stroke
Holl-O-Cylinder,1"Stroke
Order #: RWH-121
Mfg #: RWH121
Product Highlights
- Load can be attached to either end of the cylinder, providing a choice of push or pull actions - both realizing full cylinder capacity
- Very high cylinder capacities contained within small dimensions allow compact fixture designs
- Spring return operation allows for easy unloading of the workpiece
- Threaded collars and base mounting holes allow mounting flexibility, including table-top surfaces and T-slots
- Nickel-plated plungers, plunger wipers and internal venting prevent corrosion and support longer operation life on all HCS models
| Maximum Operating Pressure (psi) | 5,000 |
| Maximum Cylinder Capacity Advance (lbs) | 13,800 |
| Stroke (in) | 1.02 |
| Return Type | Single-Acting, Spring Return |
| Plunger Type | Hollow |
| Material | Steel |
| Cylinder Effective Area Advance (in2) | 2.76 |
| Oil Capacity Advance (in3) | 2.76 |
| Weight (lbs) | 4.8 |
