Hioki 3561 AC Milliohm Hi-Tester/Battery Tester

AC Milliohm Hi-Tester/Battery Tester

Order #: 3561

Mfg #: 3561

$3,457.50

Hioki products are available to ship to customers in the United States only.

Add Calibration

Qty

This product is available for shipping to the United States and Puerto Rico only.

This item is available as RENTAL at

Call for price

Shop now

The Perfect Battery Tester for the Production Line
High speed and reliable battery inspection
High precision accuracy
Choice of PC interfaces for full remote operation
Measurement ranges and Accuracy 300 m-Ohm to 3 Ohm, 2 ranges, ±0.5 % rdg. ±5 dgt. 20 V, ±0.01 % rdg. ±3 dgt. (Input imperdance 1m-ohm)
Measurement current 10 mA (300 m-Ohm range) to 1 mA (3 -Ohm range)
Max. applied measurement voltage ±22 V DC rated input voltage ±70 V DC maximum rated voltage above ground
Sampling speed Four steps: 7 ms(Extra-FAST), 23 ms(FAST), 83/69 ms(Medium), 258/251 ms(Slow)
Displays 31,000 full digits (resistance), 19.9999 full digits (voltage), Fluorescent tube
Measurement method Four-terminal AC (1kHz) method
Comparator functions Setting: Upper and lower limit Output: 3 levels (Hi, In, Lo) or (Pass, Fail), Open-collector, Display, Dual audible indicator
Panel save/load Up to 126 configuration settings
Other functions Over-range display, measurement error detection Self-calibration, dual comparators, key-lock
Interface External I/O, RS-232C , Printer(RS-232C), GP-IB(3561-01)
Power supply 100 to 240 V AC (50/60 Hz)
Dimensions, mass 215 mmW × 80 mmH × 295 mmD, 2.4 kg
